36" TracFab Gas

Take One For A Spin

You Are No Longer Limited By Battery Life!

Just Add More Fuel & Continue The Fun

The TracFab Gas features a large 5 gallon fuel tank which allows users to operate for several hours and

miles on a single tank of fuel.



17.5 Horsepower Powerplant

  • Convenient Keyed Electric Start w/ Pull Start Backup

  •  4 Stroke Reliability & Minimal Maintenance Needed

  • Quiet Operation With Powerful Output

  • Emission Compliant for All 50 States

  • 9 Amp DC Alternator

  • Made In The USA

PDF Icon.png

High Quality Seating

  • Moderate thigh bolsters make it easy to transfer in and out


  • Bolster support to minimize body shifting while driving


  • Black, grey, or tan seating color available


  • Adjustable seat-back recline angle

  • Standard 4 point harness

  • Optional 5 point harness

TracFab Gas Aluminum Wheels

  • CNC Machined from a slug of billet aluminum

  • Precision sealed ball bearings support axial and radial loads

  • Made to handle rough terrain and extreme torque

  • Left and right track controlled individually

  • Control forward / reverse of each track on the fly

  • Precision operator control over all terrains

  • Comfortable rubber control grips

Independent Track Control

Gauge and Switch Panel

  • Backlit fuel level gauge

  • Keyed ignition switch for security

  • Sealed toggle switch for optional headlights

  • LED indicators

  • Tethered engine shut off lanyard

  • Welded steel safety cage

  • Front / rear safety stabilizer wheels

  • 4 point harness

  • Automatic fuel shut off solenoid

Safety Features


Weight: 600 Pounds

Overall Width: 36 Inches

Overall Length: 61 Inches

Overall Height: 61 Inches

Seat Height From Ground: 23 Inches

Length of Track Contact to Ground: 34 Inches

Width of Each Track: 6.5 Inches

Ground Clearance: 6 Inches

Turning Radius: Zero Degree

User Weight Limit: 350 Pounds (Heavy Duty Model Available)

Drivetrain: Hydraulic & Gasoline Combustion 4 Stroke Engine

Starting: Electric Start w/ Key

Standard Seating: Corbeau Extreme Comfort Seating

Seating Options: Seat Sliders Are Optional For Easy Transferring
