Take One For A Spin


Pure Lead AGM Batteries

  • Innovative pure lead thin plate AGM technology ensures you get the most power possible


  • Faster recharge than conventional batteries


  • No water levels to check or terminals to clean


  • Full 3 year warranty


  • 8-9 Mile Range

  • Made in the USA

Powerful Precision Control

  • Large clear color LCD screen with icon-based screen controls


  • Provides fast, precise control of high power drive motors


  • Low-force joystick with proportional control


  • Optional attendant, sip and puff, chin, foot control


High Quality Seating

  • Moderate thigh bolsters make it easy to transfer in and out


  • Bolster support to minimize body shifting while driving


  • Black, grey, or tan seating color available


  • Adjustable seat-back recline angle

  • Standard 4 point harness

  • Optional 5 point harness

Custom Rehab Seating Is Available On Every Electric TracFab Model


Full Floating Seat Suspension

  • Low profile floating seat suspension


  • Floats over bumps and rough terrain


  • Fully adjustable


  • Great for spinal cord injuries

  • Added user comfort

  • Not available on competitors units

All Terrain Track System

  • Reinforced rubber tracks provide superior traction


  • Traverse mud, sand, snow, rocks


  • Sealed bearings provide a low maintenance operation


  • Adjustable tensioning system

  • 20 amp dual bank charger


  • Automatically charges, conditions and safely maintains batteries


  • Lower AC power consumption and operating costs


  • Automatic storage recondition

Waterproof  On-board Charger

Ease of Transfer

  • Flip-up arm rests move out of the way for easy transferring


  • Sturdy transfer bars


  • Rubber coated grab handles


  • Low seat height (Flat pan available)


Weight: 485 Pounds

Overall Width: 36 Inches

Overall Length: 58 Inches

Overall Height: 57 Inches

Seat Height From Ground: 27.5 Inches

Length of Track Contact to Ground: 22 Inches

Width of Each Track: 6.5 Inches

Ground Clearance: 4 Inches

Turning Radius: Zero Degree

User Weight Limit: 350 Pounds (Heavy Duty Model Available)

Drivetrain: Dual 24 Volt Gearmotors

Battery: Dual Group 31 AGM

Electronics: Dynamic Controls

Standard Seating: Corbeau

Optional Seating: Unlimited Rehab Medical Seating Available
